Eaton Vikers M Series Vane Motor 46M185A1C20 Replacement
Elephant Fluid Power manufactures Eaton Vikers M Series Vane Motor 46M185A1C20 Replacement,best quality,good price,fast lead time,and one year warranty since sales.
Technical Data:
| Model Torque Displacement Flowinput/required Series Nm/6,9 bar cm3/r(in3/r) @1200r/min (lb in/ 100 psi) L/min(USgpm) | Maximum speed & pressure | Approx. weight Kg(lb) |
| 25M 4,7 (42) 43,9 (2.68) 52,6 (13.9) 6,2 (55) 57,7 (3.52) 69,3 (18.3) 7,3 (65) 68,7 (4.19) 82,5 (21.8) | 3600 r/min @ 34 bar (500 psi) 4000 r/min @ 34 bar (500 psi) | 18 (40) |
| 35M 9,0 (80) 83,6 (5.10) 100,3 (26.5) 10,7 (95) 100,3 (6.12) 120,4 (31.8) 13,0 (115) 121,9 (7.44) 146,1(38.6) | | 29 (64) |
| 45M 14,7 (130) 138,0 (8.42) 165,4 (43.7) 17,5 (155) 163,2 (9.96) 195,7 (51.7) 20,9 (185) 193,2(11.79) 232,0 (61.3) | 2600 r/min @ 155 bar (2250 psi) 3000 r/min @ 172 bar (2500 psi) | 39 (85) |
| 50M 24,9 (220) 231,2 (14.11) 277,5 (73.3) 28,8 (255) 268,1 (16.36) 321,8 (85.0) 33,9 (300) 317,1 (19.35) 380,4 (100.5) | 2800 r/min @ 34 bar (500 psi) 3200 r/min @ 34 bar (500 psi) 2200 r/min @ 155 bar (2250 psi) 2400 r/min @ 172 bar (2500 psi) | 73 (160) |
Our main hydraulic vane motors models are as followings:
| 25M30A1A20117 | 35M115A1C20141 | F8-25M55A11C20 | 45M130A1C20141 | 25M35A1C20 | 25M42A1C20 |
| 25M30A1C20117 | F8-35M95A11C20 | F8-25M65A1C20 | F8-45M130A11C20 | 25M65A11C20139 | 35M80A1C20141 |
| 25M42A11C20 | F8-35M95A1C20 | F8-25M65A11A20 | 50M300A11C20L143 | F8-25M42A1C20 | 35M95A1C20141 |
| 25M55A11C20 | 45M130A1A20 | F8-25M65A11C20 | 50M300A11C20R144 | F8-25M42A11C20 | 45M155A1C20 |
| 25M65A1A20 | 45M130A1C20 | 35M95A11C20 | 50M300A11C20139 | F8-25M55A1C20 | 50M220A11C20139 |
| 25M65A1C20 | 45M130A11A20 | 35M80A11C20 | F8-50M300A11C20L143 | 45M185A1A20 | 50M255A1C20141 |
| 25M65A11C20 | 45M130A11C20 | 35M115A11C20 | F8-50M300A11C20L143L | 45M185A1C20 | 35M95A1C20 |
| 25M55A1A20 | 45M155A11C20 | 35M80A1A20 | 50M300A11C20114 | 45M130A1C20139 | 50M220A1C20141 |
| 25M55A1C20 | 45M185A11C20 | 35M80A1C20 | 50M255A11A20114 | 45M155A1C20141 | 50M300A1C20141 |
| 25M42A1A20 | 45M155A1A20 | 35M95A1A20 | 50M300A1A20114 | 45M185A1C20141 | F8-50M300A1C20114 |
| 50M255A1C20114 | 35M115A1C20 | 50M220A1C20114 | 50M300A1C20114 | 35M115A1A20 | F8-35M115A11C20 |
| 26M30A1A20117 | 36M115A1C20141 | F8-26M55A11C20 | 46M130A1C20141 | 26M36A1C20 | 26M42A1C20 |
| 26M30A1C20117 | F8-36M95A11C20 | F8-26M65A1C20 | F8-46M130A11C20 | 26M65A11C20139 | 36M80A1C20141 |
| 26M42A11C20 | F8-36M95A1C20 | F8-26M65A11A20 | 51M300A11C20L143 | F8-26M42A1C20 | 36M95A1C20141 |
| 26M55A11C20 | 46M130A1A20 | F8-26M65A11C20 | 51M300A11C20R144 | F8-26M42A11C20 | 46M155A1C20 |
| 26M65A1A20 | 46M130A1C20 | 36M95A11C20 | 51M300A11C20139 | F8-26M55A1C20 | 51M220A11C20139 |
| 26M65A1C20 | 46M130A11A20 | 36M80A11C20 | F8-51M300A11C20L143 | 46M185A1A20 | 51M265A1C20141 |
| 26M65A11C20 | 46M130A11C20 | 36M115A11C20 | F8-51M300A11C20L143L | 46M185A1C20 | 36M95A1C20 |
| 26M55A1A20 | 46M155A11C20 | 36M80A1A20 | 51M300A11C20114 | 46M130A1C20139 | 51M220A1C20141 |
| 26M55A1C20 | 46M185A11C20 | 36M80A1C20 | 51M265A11A20114 | 46M155A1C20141 | 51M300A1C20141 |
| 26M42A1A20 | 46M155A1A20 | 36M95A1A20 | 51M300A1A20114 | 46M185A1C20141 | F8-51M300A1C20114 |
| 51M265A1C20114 | 36M115A1C20 | 51M220A1C20114 | 51M300A1C20114 | 36M115A1A20 | F8-36M115A11C20 |
FAQ:
Q:What Is Our Main Application?
A:1.Hydraulic system
2.Agriculture machine
3.Construction machine
4.Automobile
5.Local distributors
Q:What Is The Payment Terms?
A:Full order:30% as desposit, the balance before shipment:
Small order /sample ordre: full payment in advance:
Q:Can I Mark My Own Brand On The Pump?
A:Yes. Full order can mark your brand and code.
Q:What Is Our Main Export Market?
A:Europe (41.7%):Italy,Germany,England,France,Holland,Greece,Spain,Portugal,Swissland,Finland,Czekh,Russia,Poland
Asia(40.5%):China,Korea,Singapore,India,Turkey,Iran,Vietnam,Saudi Arabia,Syria,Isreal,Lebanon
Q:How Long Is Guarantee?
A:We give 1 year guarantee.
Our main vane pumps and cartridges models are as followings:
| Series | Model |
| T6 Single Pump: | T6C, T6D, T6E |
| T6 Double Pump: | T6CC, T6DC, T6EC, T6ED,T6DR,TGC |
| T6 Treble Pump: | T6DCC, T6DDCS, T6EDC, T6EDCS |
| Denison Cartridge Kits type: | T6C, T6D, T6E, T7B, T7D, T7E |
| T6C single pump & cartridge: | 003, 005, 006, 008, 010, 012, 014, 017, 020, 022, 025, 028, 031 |
| T6D, T7D single pump & cartridge: | 014, 017, 020, 024, 028, 031, 035, 038, 042, 045, 050, 061 |
| T6E, T7E single pump & cartridge: | 042, 045, 050, 052, 057, 062, 066, 072, 085 |
Our company has rich experience in repairing various imported and domestic hydraulic components such as plunger pumps, motors, reducers and so on. The company has advanced hydraulic pump test benches, and is equipped with professional hydraulic system engineers, maintenance engineers have rich practical maintenance experience. Products are widely used in roadheaders, excavators, concrete mixers, concrete pump trucks, pumping stations, pavers, road rollers, road mixers, hydraulic hoists, steel rolling machines, injection molding machines, petroleum equipment, environmental protection and other hydraulic machinery. Covers construction machinery, construction machinery, metallurgical machinery, mining machinery, hoisting machinery, injection molding machinery, chemical machinery, petroleum, shipping, environmental protection and other fields. The company has flexible mechanism, good reputation, good service and reliable product quality.
